The Lightera LGX Optical Fiber Management Termination Shelves, regarded as the original
fiber frame solution, are used to complete existing 19 or 23 fiber frame installations.
Available in 7 and 9 high versions, the LGX termination shelves can be combined to
create “design specific” solutions and meet your application needs. They can also hold
many of the standard industry adapter types like the LC, SC, ST, and FC.
The Lightera LGX Optical Fiber Management Termination Shelves, regarded as the original
fiber frame solution, are used to complete existing 19 or 23 fiber frame installations.
Available in 7 and 9 high versions, the LGX termination shelves can be combined to
create “design specific” solutions and meet your application needs. They can also hold
many of the standard industry adapter types like the LC, SC, ST, and FC.
The Lightera LGX Optical Fiber Management Termination Shelves, regarded as the original
fiber frame solution, are used to complete existing 19 or 23 fiber frame installations.
Available in 7 and 9 high versions, the LGX termination shelves can be combined to
create “design specific” solutions and meet your application needs. They can also hold
many of the standard industry adapter types like the LC, SC, ST, and FC.
| LGX FO Termination Shelf Ordering Information* | ||
|---|---|---|
| Empty Termination Shelves | Comcode | Shelf Height (inches) |
| LST1F-07-WHT SHELF | 106191695 | 7 |
| LST1F-09-WHT SHELF | 300429636 | 9 |
| LST1U-07-BLK SHELF | 109182303 | 7 |
| LST1U-07-WHT SHELF | 105335871 | 7 |
| LST1U-09- BLK SHELF | 108875998 | 9 |
| LST1U-09-WHT SHELF | 107535569 | 9 |
| LGX FO Termination Shelf Ordering Information* | ||||
|---|---|---|---|---|
| Termination Shelves Equipped with Panels And/or Adapters | Comcode | Shelf Height (inches) | Adapter Type Installed | Adapter Count |
| LST1F-072-07- WHT-LCU/LCA (60/12) | 300570751 | 7 | LCU (60) LCA (12) | 72 |
| LST1U-036-07- WHT-C3000A-2 ST (SM) | 300585569 | 7 | ST SM C3000A-2 | 36 |
| LST1U-072-07- WHT-12-1000ST1 | 107075160 | 7 | only panels | 72 |
| LST1U-072-07- WHT-C2000A-2 ST (MM) | 107640609 | 7 | ST MM C2000A-2 | 72 |
| LST1U-072-07- WHT-C3000A-2 ST (SM) | 107525131 | 7 | ST SM C3000A-2 | 72 |
| LST1U-072-07- WHT-FC ADPTRS (SM/MM) | 300536091 | 7 | FC SM/MM | 72 |
| LST1U-072-07- WHT-LC SIMPLEX ADPTRS (SM) | 109062059 | 7 | LC SM Simplex C1101A-1 | 72 |
| LST1U-072-07- WHT-SC (SM) | 106500614 | 7 | SC SM C6000A-4 | 72 |
| LST1U-072-07- WHT-SC Pnl Recessed (panel is bent to give front door relief when using attenuators) | 300414224 | 7 | SC SM C6000A-4 | 72 |
| LST1U-072-07- WHT-SCA C-6800A-4 | 301015970 | 7 | SCA C6800A-4 | 72 |
| LST1U-072-07- WHT-STSM A3072 | 301015111 | 7 | ST SM A3072 UMA | 72 |
| LST1U-096-07 WHT-SC (MM) | 300560117 | 7 | SC MM C6001A-4 | 96 |
| LST1U-096-07- WHT-C2000 ST (MM) | 107933251 | 7 | ST MM C2000A-2 | 96 |
| LST1U-096-07- WHT-C3000A-2 ST (SM) | 300573722 | 7 | ST SM C3000A-2 | 96 |
| LST1U-096-07- WHT-SC (SM) | 109136119 | 7 | SC SM C6000A-4 | 96 |
| LST1U-096-07- WHT-SCA C-6800A-4 | 300498896 | 7 | SCA C6800A-4 | 96 |
| LST1U-144-09-BLK-SCA ADPTRS (SM) | 301014916 | 9 | SCA C6800A-4 | 144 |
| LST1U-144-09- WHT-LC SM SMPLX ADPTRS | 109086090 | 9 | LC SM Simplex C1101A-1 | 144 |
| LST1U-144-09- WHT-SC (SM) | 107871337 | 9 | SC SM C6000A-4 | 144 |
| LST1U-144-09- WHT-SCA ADPTRS (SM) | 300580396 | 9 | SCA C6800A-4 | 144 |
| LST1U-144-09- WHT-ST ADPTRS (MM) | 108363813 | 9 | ST MM A2000A-2 | 144 |
| LST1U-144-09- WHT-ST ADPTRS (SM) | 108363722 | 9 | ST SM A3000A-2 | 144 |
| LST2U-048-07- WHT-SC A3063 | 300411469 | 7 | SCU A3063 UMA | 48 |
| LST2U-072-07 WHT-SC/FC A3083 | 300584778 | 7 | SC/FC A3083 UMA | 72 |
| LST2U-072-07- WHT-72-A3002 (ST BASE) | 108632019 | 7 | ST Base only | 72 |
| LST2U-072-07- WHT-72-A3003 (SC BASE) | 109106153 | 7 | SC Base only | 72 |
| LST2U-072-07- WHT-ST/SC A3062 | 301006078 | 7 | ST/SC SM A3062 UMA | 72 |
| LST4U-072-07- WHT-36-LC LP DPLX ADPTRS (SM) | 301006672 | 7 | LC SM Duplex C1104A-2 | 72 |
| LST4U-108-07- WHT-LC MM C1004B-2 | 301006623 | 9 | LC MM C1004B-2 | 108 |
| LST4U-144-07- WHT-LC SM DPLX ADPTRS | 301006680 | 9 | LC SM Duplex C1104A-2 | 144 |
| LST4U-192-07- WHT-LC MM C1004A-2 | 301009684 | 9 | LC MM C1004B-2 | 192 |
| LST4U-288-07-BLK LC DPLX | 301012399 | 9 | LC SM Duplex | 288 |
| LST5U-072-07-BLK-MMC6SC AQUA | 109171520 | 7 | SC MM C6MMSC-LW | 72 |
| LST5U-072-07-BLK-MMC6ST AQUA | 109171538 | 7 | ST MM C6MMST-LW | 72 |
| LST5U-144-07-BLK-MMC12LC AQUA | 109171512 | 9 | LC MM C12MMLC-LW | 144 |
| * LST1U Standard Patch Panel which allows jumpers in the front and cable entry in the rear | ||||
| LST1F Front Access Shelf where the panel folds out to provide access to the front | ||||
| Panel Ordering Information | ||||
|---|---|---|---|---|
| Description | Comcode | Adapter Type | Shelf Size (in.) | Ports/Panel |
| 1000FC1-6 E/W ADAPTERS | 106225923 | FC (SM/MM) | 7 | 6 |
| 1000LC-6 E/W SMPLEX (SM) | 300398435 | LC | 7 | 6 |
| 1000LCA-6 E/W SIMPLEX (SM) | 300398443 | LCA | 7 | 6 |
| 1000SC1-8 E/W SC (SM) | 107187650 | SC | 7 | 8 |
| 1000SC1-6 E/W SC (SM) | 106500630 | SC | 7 | 6 |
| 1000SC1-6 E/W SC SM OFF CENTER | 300410420 | SC (A3063) | 7 | 6 |
| 1000SCA-6 E/W (A3863) | 300407137 | SCA (A3863) | 7 | 6 |
| 1000ST1-6 E/W ST (SM) | 106500622 | ST (SM) | 7 | 6 |
| 1000ST1-8 E/W ST (SM) | 107187643 | ST (SM) | 7 | 8 |
| PNL 7" EW SM/C12LC BLUE | 109171785 | LC Ganged | 7 | 12 |
| PNL 7" EW SM/C6SC BLUE | 109171793 | SC Ganged | 7 | 6 |
| PNL 7" EW SM/C6ST BLUE | 109171801 | ST Ganged | 7 | 6 |
| 1200SC1-12 E/W SC (SM) | 107719049 | SC | 9 | 12 |
| 1200ST1-12 E/W ST (SM) | 107723439 | ST (SM) | 9 | 12 |
| Accessories for Termination Shelf | ||
|---|---|---|
| Product Code | Comcode | Description |
| 12A1 Clamp | 104384490 | Metallic Sheath Cable Clamp |
| 12A2 Clamp | 106230337 | Dielectric Sheath Cable Clamp |
| 12A1 Clamp w/o strap | 301006888 | Metallic Sheath Cable Clamp without the ground strap |
| 12A3L Clamp | 108527433 | Metallic and Dielectric Cables .25” to 1.5” up to 864 Cable Lightera |
| S1-1X2-1315-SCA-S-BAL-F | 300387610 | Balanced 1X2 splitter with SCA input and output |
| S1-1X4-1315-LCA-S-BAL-F | 300387214 | Balanced 1X4 splitter with LCA input and output |
| S1-1X16-FULL-MPO/SCA-S-BAL-F | 300574191 | Balanced 1X16 splitter with SCA input and MPO output |
