Code -
06827-01
Sliding Plastic Shelf 1U P-LIU
Lightera offers a sliding plastic shelf with a new innovative design. The Lightera 1U Series Combination Shelf in plastic helps you to save time and money using different features like fiber management and frontal fiber guide to protect your network and to permit quick rearrangement.
The 1U plastic sliding shelf houses up to 48 fusion splices using LC terminations or 24 fusion splices using SC terminations.
Lightera offers a sliding plastic shelf with a new innovative design. The Lightera 1U Series Combination Shelf in plastic helps you to save time and money using different features like fiber management and frontal fiber guide to protect your network and to permit quick rearrangement.
The 1U plastic sliding shelf houses up to 48 fusion splices using LC terminations or 24 fusion splices using SC terminations.
Features
- Slim 1U mounting height (1U rack space)
- Front-mounted jumper management guide
- Easy cable fixation
- Intuitive fiber arrangement
- Sliding lateral supports
- Transparent plastic top cover with fiber routing label
- Bottom access to jumper connections
- Optional extender brackets for 23” frame
Product Description
Lightera offers a sliding plastic shelf with a new innovative design. The Lightera 1U Series Combination Shelf in plastic helps you to save time and money using different features like fiber management and frontal fiber guide to protect your network and to permit quick rearrangement.
The 1U plastic sliding shelf houses up to 48 fusion splices using LC terminations or 24 fusion splices using SC terminations.
Product characteristics
| Product Characteristics | |
|---|---|
| Dimensions | 484 (W) X 44 (H) X 270 (D) [mm] |
| Cable Entrance | Up to Ø 15mm |
| Sliding System | Yes (70 mm) |
| Top Cover | Yes (transparent plastic material) |
| Material | ABS + Polycarbonate |
| Fusion Splicing Capacity | Up to 48 |
| Adapter Capacity | Up to 24 SC or LC types |
| Product Certification | UL Listed |
| Frontal Cable Management | Yes |
Ordering Information
| Ordering Information | |
|---|---|
| Comcode | Product Code |
| 301133237 | 1U P-LIU-LC24 DUPLEX AQUA |
| 301133245 | 1U P-LIU-LC24 DUPLEX AQUA PT OM3 |
| 301133252 | 1U P-LIU-LC48 DUPLEX AQUA |
| 301133260 | 1U P-LIU-SC24 SIMPLEX AQUA |
| 301133278 | 1U P-LIU-SC24 SIMPLEX AQUA PT OM3 |
| 301133286 | 1U P-LIU-LC24 DUPLEX AQUA |
| 301133294 | 1U P-LIU-LC24 DUPLEX AQUA PT OM4 |
| 301133302 | 1U P-LIU-LC48 DUPLEX AQUA |
| 301133310 | 1U P-LIU-SC24 SIMPLEX AQUA |
| 301133328 | 1U P-LIU-SC24 SIMPLEX AQUA PT OM4 |
| 301133336 | 1U P-LIU-LC24 DUPLEX BEIGE |
| 301133344 | 1U P-LIU-LC24 DUPLEX BEIGE PT OM2 |
| 301133351 | 1U P-LIU-LC48 DUPLEX BEIGE |
| 301133369 | 1U P-LIU-SC24 SIMPLEX BEIGE |
| 301133377 | 1U P-LIU-SC24 SIMPLEX BEIGE PT OM2 |
| 301133385 | 1U P-LIU-LC24 DUPLEX BLUE |
| 301133393 | 1U P-LIU-LC24 DUPLEX BLUE PT |
| 301133401 | 1U P-LIU-LC48 DUPLEX BLUE |
| 301133419 | 1U P-LIU-SC24 SIMPLEX BLUE |
| 301133427 | 1U P-LIU-SC24 SIMPLEX BLUE PT |
| 301133435 | 1U P-LIU-LC24 DUPLEX GREEN |
| 301133443 | 1U P-LIU-LC24 DUPLEX GREEN PT |
| 301133450 | 1U P-LIU-LC48 DUPLEX GREEN |
| 301133468 | 1U P-LIU-SC24 SIMPLEX GREEN |
| 301133476 | 1U P-LIU-SC24 SIMPLEX GREEN PT |
Contact Information
For additional information please contact your sales representative. You can also visit our website at www.lightera.com or call 1-888-FIBERHELP (1-888-342-3743) USA or 1-770-798-555 outside the USA. For a full list of our certifications, visit our website.
Trademark Notice and Disclaimer
Lightera reserves the right to make changes to the product(s) described in this document at any time without notice. This document is for informational purposes only and is not intended to modify or supplement any Lightera warranties or specifications relating to any of its products or services.
